Medicine Rapid Mixer Granulator
Medicine Rapid Mixer GranulatorMedicine Rapid Mixer GranulatorMedicine Rapid Mixer GranulatorMedicine Rapid Mixer Granulator
Medicine Rapid Mixer GranulatorMedicine Rapid Mixer GranulatorMedicine Rapid Mixer GranulatorMedicine Rapid Mixer Granulator

Medicine Rapid Mixer Granulator

Share
  • Specification
  • Features
  • Structure
  • Technology data
  • Machine Pics

(1)GHL Medicine Rapid Mixer Granulator Series is a new style of pharmaceutical equipment built around the YK Granulator. It can quickly blend and combine dry powder and glue, then break the resulting substance into pieces. It complies with the GMP Standard.


(2) The high speed mixer granulator is extensively used in the pharmaceutical, chemical, food, powder metallurgy, cosmetic, and dyeing industries, among others.


(3) The benefits include great efficiency, quickness, evenness, and mixing and granulating in one chamber.


ensuring that the pigment or coloring granules are dispersed uniformly;

high blending capacity: rapidly saturating the material with an 8–12% starch slurry;


assessing the granulating status based on the maximum electrical use;


the granules used in manufacture are loose and resemble snow, with more particles and less powder;


the three processes of mixing, wetting, and granulating are carried out concurrently in a single barrel without the use of any physical labor;


if the proper conditions are fulfilled, such as the timing and rate of mixing and granulating, the amount of glue used, the amount of energy used, etc., it may be produced again;


The machine's primary components include a blending system, a cutting system, a frame, a mixing barrel, an electric control box, etc. The motor, the bearing pedestal, and the cutting knife make up the blender system. To stop raw materials from running into the transmission shaft and prevent lubricant contamination, the blending system and cutting system include airproof devices.

TypeGHL-50GHL-150GHL-200GHL-250GHL-300GHL-400
Volume (L)50150200250300400
Capacity (kg/batch)155080100130200
Blending speed (rpm)300/210270/180270/180188/130160/110120/85
Blending power (KW)4/5.59/1111/1411/1411/1415/17
Cutting power (KW)1.5/2.22.4/33.3/43.3/44.5/5.56.5/8
Cutting speed (rpm)1440/2900
Working time (min)8-15
Particle size (mesh)20-80



Medicine Rapid Mixer Granulator
