LINGLING fertilizer powder high speed shear mixer granulator wet mixing granulation RMG machine

The GHL Series represents a new kind of machinery used in the pharmaceutical, medicine, food, and chemical industries. It's designed by applying the principle of the one-step granulator. This series can quickly blend and mix dry powder, turning it into even wet powder and then granules. What's more, it complies with the GMP Standard, ensuring high quality and safety for production.

1. **Even Mixing**: Guarantees that coloring particles or pigment are spread out uniformly, ensuring a consistent appearance. 2. **Powerful Blending Capacity**: Can swiftly wet materials using 8 - 12% thick starch slurry, enhancing the mixing process. 3. **Granulating Monitoring via Max Power Consumption**: Allows for gauging the granulating progress by keeping an eye on the peak electricity usage. 4. **High-Quality Granules**: Produces loose, snow-like granules without clumps, having more particles and minimal powder content, which is ideal for further processing. 5. **Integrated and Continuous Process**: The mixing, wetting, and granulating steps occur continuously in a single barrel, reducing the risk of manual contamination and streamlining production. 6. **Reproducible Results**: With the right settings like mixing and granulating time, adhesive and electricity consumption, it can consistently produce the same quality output. 7. **Efficient Production**: The mixer granulator can complete a production cycle in approximately ten minutes, yielding granules that compress well, boosting overall productivity. 8. **Broad Applicability**: Can be integrated into a pipeline with a one-step fluidized granulator and a fluidized drier, expanding its usability in different production setups. 9. **Cost and Time Savings**: Saves around 20 - 25% of the adhesive needed and cuts down the drying time, reducing production costs. 10. **Outstanding Features**: Boasts an advanced design, a logical layout, reliable sealing, easy operation, and high safety and reliability standards, making it a top choice for various industries.

(1) This machine is mainly made up of several parts, including the blending system, cutting system, frame, mixing barrel, and electric control box. The blending system comprises a motor, a bearing pedestal, and cutter knives. Both the transmission shaft of the blending system and that of the cutter system are equipped with airproof devices. These are to stop raw materials from getting into the shafts and to prevent lubricant pollution. (2) The mixing barrel is firmly attached to the frame. It's crafted from SUS304 high-grade stainless steel, which makes it strong, long-lasting, and resistant to rust. Its bottom is columnar and the tip is conical, ensuring there are no dead angles. This allows for even mixing and easy cleaning. On the side of the mixing barrel, there's a pneumatic valve for discharging. The entire valve is connected by a hinge, so it can be easily moved away for thorough inspection and cleaning. (3) Between the mixing barrel and the barrel cover, there's a silicon rubber airproof ring. The extended parts of the two transmission shafts are also sealed to keep contaminants out of the barrel. (4) For safety, when the barrel cover and the discharge exit are open, the blending system and the cutter system cannot be started. This safeguard protects operators from potential hazards.
