This sugar crushing machine features a dust collecting box, produces no dust while it is operating, and complies with GMP requirements. Many businesses in the food and pharmaceutical industries use this grinder.Additionally, the automated discharge mechanism for this sugar crushing allows for continuous discharge without air pressure. can actually operate constantly for 24 hours.
The device uses the relative motion between the active and stationary fluted discs, as well as collision between the materials, to crush and grind the materials. By spinning a centrifugal force function, crushed materials are fed into the capture bag, and the dust is collected and recycled by a dust collector using a bag filter box. This GMP-compliant equipment, which is entirely constructed of stainless steel elements, produces no flying dust. It has currently evolved to an international level and can increase material utilization rates while lowering corporate costs.
1. The WFC Dry Sugar grinding machine may be designed to fit turbine blades as well as other types of blades if the customer requests it. so that the user can switch to a different blade)
2. The WFC Dry Sugar grinding machine incorporates a mechanism for chilling water.
3. The WFC Dry Sugar grinding machine has a magnetic attachment to get rid of metal impurities (per customer need).
4.The WFC Dry Sugar grinding machine may be used with both the general and pulse dust absorption systems.
None
| Model | Capacity (kg) | Feed size(mm) | Output size(mesh) | Total power(kw) | Main speed(r/min) | Dimension(mm) | Weight (kg) |
| WF-30C | 50-300 | <10 | 12-120 | 11.75 | ~3800 | 6000*1200*2900 | 700 |
| WF-40C | 80-400 | <12 | 13.75 | ~3400 | 6300*1300*2900 | 1000 | |
| WF-50C | 100-500 | <12 | 17.25 | ~2900 | 7000*1500*2900 | 1200 | |
| WF-60C | 300-800 | <15 | 33.75 | ~2400 | 7500*1500*3650 | 1500 | |
| WF-80C | 400-1500 | <15 | 60.1 | ~2200 | 8400*2500*4850 | 2000 |
