WFJ Super Micro Fine Grinder

Spices Micro Fine Grinder
Spices Micro Fine GrinderSpices Micro Fine Grinder
Spices Micro Fine GrinderSpices Micro Fine Grinder

Spices Micro Fine Grinder

Share
  • Specification
  • Features
  • Structure
  • Technology data
  • Machine Pics

Spices Micro Fine Grinder has the advantages of wind selection, not requiring a sieve or net, and producing processed material with an equal granularity. The machine is capable of grinding chemical products while the production process is ongoing. dietary supplements, medications, cosmetics, colors, resins, cotourants, grains, etc.

1.Spices Micro Fine Grinder Simple construction is simple to install and maintain.

2.The Spices Micro Fine Grinder uses cutting-edge, well-known brand electric and mechanical components.

3.Spices Micro Fine Grinder Dust may be collected in a dust collecting box, and there is no dust throughout production.



By way of a screw conveyor, material is fed into the Spices Micro Fine Grinder, where it is quickly spinning blades shear and grind the material. The powder enters the classification chamber after passing the guiding ring. Both air force and centrifugal force operate on the powder while the classifying wheel rotates. While the particles whose diameters are smaller than the critical diameter enter the cyclone separator and dust-collecting box, those whose diameters are greater than the critical diameter (diameter of the classification particles) are thrown back into the mill chamber to be ground again because of their higher mass.

ModelWFJ-10WFJ-15WFJ-20WFJ-30WFJ-60WFJ-80WFJ-100
Production Capacity (kg)10~5050~10080~200200~400400~800500~1000600~1200
Feeding size (mm)<5<10<10<12<12<12<12
Crushing fineness (mesh)80-600
Motor power (kw)1213.3718.3742.577.596138
Spindle speed (rpm)4000580042003800320028002000
Weight (kg)500100012001800250030004000
Overall  dimension
(L*W*H)(mm)
1700x1800x22004500x1250x27006000x1250x29007100x1300x36508000x2300x45008500x2500x460010000x2800x5000

*The above specifications are provided for reference only. We can also design and manufacture different standard upon customer's request.
