The Cinnamon Powder Grinder is made up of three essential components. The main machine takes the lead in pulverizing cinnamon into fine powders. The auxiliary part plays a crucial role in guaranteeing seamless operation. And the electric control box skillfully oversees all functions. When these three work in unison, the machine can grind cinnamon outstandingly, attaining powders of high precision and top quality.
1. The LL Cinnamon Powder Grinder has a sleek look that simplifies installation and maintenance. Its simple structure means no trouble during setup. 2. Equipped with premium parts from well-known brands, it guarantees excellent performance. 3. It operates without dust as all is collected in the box, keeping the workspace tidy. 4. No need for a screen; just adjust the speed within 80 - 600 mesh to get the desired particle size. 5. The cooling jacket effectively cools the machine, ensuring smooth operation.
Material gets into the Cinnamon Powder Grinder through a screw conveyor. The fast-spinning blades chop and grind it. Once past the guide ring, it enters the classification chamber. Larger particles are tossed back for more grinding, while smaller ones head to the cyclone separator and dust box.
| Model | WFJ-10 | WFJ-15 | WFJ-20 | WFJ-30 | WFJ-60 | WFJ-80 | WFJ-100 |
| Production Capacity (kg) | 10~50 | 50~100 | 80~200 | 200~400 | 400~800 | 500~1000 | 600~1200 |
| Feeding size (mm) | <5 | <10 | <10 | <12 | <12 | <12 | <12 |
| Crushing fineness (mesh) | 80-600 | ||||||
| Motor power (kw) | 12 | 13.37 | 18.37 | 42.5 | 77.5 | 96 | 138 |
| Spindle speed (rpm) | 4000 | 5800 | 4200 | 3800 | 3200 | 2800 | 2000 |
| Weight (kg) | 500 | 1000 | 1200 | 1800 | 2500 | 3000 | 4000 |
| Overall dimension (L*W*H)(mm) | 1700x1800x2200 | 4500x1250x2700 | 6000x1250x2900 | 7100x1300x3650 | 8000x2300x4500 | 8500x2500x4600 | 10000x2800x5000 |
*The above specifications are provided for reference only. We can also design and manufacture different standard upon customer's request.
