1. Through the relative motion between the discs, the material is crushed by impact and friction
2. The crushed material flows into the cyclone separator through the blower,discharged through the blower
3. The dust enters the dust box and is filtered
1. No need sieves, the particles are uniform, and the material can be processed continuously
2. Compact design and reasonable structure
3. Coconut grinding machine with fan for continuous heat dissipation
4. Smooth operation, low vibration and noise
5. Because of the cyclone separator and dust box, there is no dust flying phenomenon in production
6. The fine powder collected by the dust bag can be recycled to reduce material loss
1. Through the relative motion between the discs, the material is crushed by impact and friction
2. The crushed material flows into the cyclone separator through the blower,discharged through the blower
3. The dust enters the dust box and is filtered
| Model | WFJ-10 | WFJ-15 | WFJ-20 | WFJ-30 | WFJ-60 | WFJ-80 | WFJ-100 |
| Production Capacity (kg) | 10~50 | 50~100 | 80~200 | 200~400 | 400~800 | 500~1000 | 600~1200 |
| Feeding size (mm) | <5 | <10 | <10 | <12 | <12 | <12 | <12 |
| Crushing fineness (mesh) | 80-600 | ||||||
| Motor power (kw) | 12 | 13.37 | 18.37 | 42.5 | 77.5 | 96 | 138 |
| Spindle speed (rpm) | 4000 | 5800 | 4200 | 3800 | 3200 | 2800 | 2000 |
| Weight (kg) | 500 | 1000 | 1200 | 1800 | 2500 | 3000 | 4000 |
| Overall dimension (L*W*H)(mm) | 1700x1800x2200 | 4500x1250x2700 | 6000x1250x2900 | 7100x1300x3650 | 8000x2300x4500 | 8500x2500x4600 | 10000x2800x5000 |
*The above specifications are provided for reference only. We can also design and manufacture different standard upon customer's request.
