This machine is a full stainless steel mixer. On its horizontal ribbon mixer shaft, transmission screw blades are arranged. The internal spiral moves the material in the direction away from the discharge port, while the external spiral transports the material towards the discharge port.
The LINGLING WLDH liquid ribbon mixer mainly comprises a box, a stirring device, a support, a flip part, and a transmission part. This WLDH liquid mixer is crafted from stainless steel, ensuring durability and resistance to corrosion, which makes it suitable for various liquid mixing applications.
None
| Model | All Volume | Load efficiency | Power (kw) | Overall size(mm) | weight (kg) |
| WLDH-200 | 200L | 0.4-0.8 | 3 | 1190x740x770 | 330 |
| WLDH-300 | 300L | 4 | 2030x630x980 | 720 | |
| WLDH-500 | 500L | 7.5 | 2320×730×1130 | 980 | |
| WLDH-1000 | 1000L | 11 | 2800×920×1320 | 1700 | |
| WLDH-1500 | 1500L | 11 | 3180×1020×1550 | 1800 | |
| WLDH-2000 | 2000L | 15 | 3310×1120×1640 | 2100 | |
| WLDH-3000 | 3000L | 18.5 | 3750×1290×1820 | 3000 | |
| WLDH-4000 | 4000L | 22 | 4220×1400×1990 | 3980 | |
| WLDH-5000 | 5000L | 22 | 4220×1500×1990 | 4620 | |
| WLDH-6000 | 6000L | 30 | 4700×1610×2260 | 6180 | |
| WLDH-8000 | 8000L | 37 | 4420×2150×2470 | 8200 | |
| WLDH-10000 | 10000L | 45 | 5520×2960×2720 | 8920 | |
| WLDH-12000 | 12000L | 45 | 5720×3010×2840 | 9520 | |
| WLDH-15000 | 15000L | 55 | 5840×3540×2940 | 9950 |
