The vibration fluid bed dryer is a continuous type drying machine. When the material enters the machine from the inlet,under the action of vibration force, the material is thrown forward in a continuous motion in the horizontal direction. The hot air passes through the fluidized bed and the wet material transfers heat upward.finally product will go out from the discharge part.
1, Vibration adopts vibration motor drive, smooth operation, easy maintenance, low noise, long life.
2, Flow uniformity, no dead space and blow through phenomenon, can get uniform drying, cooling, humidification products.
3, Good adjustability, wide applicability. The thickness of the material layer and the moving speed in the machine as well as the change of the full amplitude can realize stepless regulation.
None
| Model | Bed body | Dimension | Vibrate power(kw) | Weight(kg) |
| L×W(mm) | L×W×H(mm) | |||
| 3×30 | 3000×300 | 3505×890×1830 | 2×0.75 | 1240 |
| 3×45 | 4500×300 | 5005×1116×1830 | 2×0.75 | 1570 |
| 4.5×45 | 4500×450 | 5005×1132×1900 | 1.1×2 | 1670 |
| 6×60 | 6000×600 | 6510×1286×1940 | 2×1.5 | 2743 |
| 6×75 | 7500×600 | 8010×1286×1940 | 2×2.2 | 2886 |
| 9×60 | 6000×900 | 6510×1830×2110 | 2×2.2 | 3540 |
| 9×75 | 7500×900 | 8010×1830×2110 | 2×3.7 | 4219 |
| 12×75 | 7500×1200 | 8010×2400×2450 | 2×5.5 | 5223 |
| 15×75 | 7500×1500 | 8010×2850×2570 | 2×5.5 | 6426 |
| 18×80 | 8000×1800 | 8520×3250×3100 | 2×7.5 | 8600 |
